Product Introduction
A high-temperature fiber optic web guide sensor is a non-contact edge detection sensor designed for web guiding (EPC) applications in high-temperature environments. By separating the optical sensing head from the electronic unit via optical fibers, it ensures stable and reliable operation in ovens, thermal stretching, and heat-treatment zones.
Main Features
- High Precision & Robustness: Achieves 0.01mm detection accuracy with high EMI immunity.
- Excellent Heat Resistance: Sustains long-term operation at 200°C, with a peak capacity of 300°C.
- IP67 protection grade: Fully operational in environments with water spray or condensation.
- Explosion-Proof Compatible: Through-beam fiber optic probes allow for safe use in hazardous areas.
- Customizable Range: Available with extended detection widths upon request.
Typical applications
- Lithium battery electrode production lines (coating and oven sections)
- Film stretching and thermal setting lines
- Metal foils (copper foil, aluminum foil)
- High-temperature coating, drying, and heat-treatment equipment
Technical Specifications
|
Detection Range |
10 mm |
|
Resolution |
0.01mm |
|
Output Signal |
0-10mA |
|
Power Supply |
12VDC/0.1A |
|
U-Shaped Slot Width |
50mm |
|
Operating Temperature Range |
−10°C to +300°C |
|
Protection Rating |
IP67 |
Drawings
